Capacity:......
Introduction: Vertical three-axis mixer (dispersion, stirring, emulsification), this equipment is a product designed by Fuvoliqiang Company with multiple functions such as.....
Vertical three-axis mixer (dispersion, stirring, emulsification), this equipment is a product designed by Fuvoliqiang Company with multiple functions such as dispersion, emulsification, stirring, etc.; this equipment is very good for medium to high viscosity and thixotropic materials The adaptability, a variety of stirring methods are available, conventional such as anchor type, butterfly type, frame type, etc., dispersion, emulsification and stirring can be carried out at the same time, strong adaptability, and can be carried out according to the characteristics of the customer's material and production process requirements Non-standard customization.
model | Stirring power (kW) | Working speed (rpm) | Dispersed power (kW) | Speed (rpm) | Lifting stroke (mm) | Processing capacity (L) |
NYSZ-500 | 2.2 | 43 | 15 | 0 ~1440 | 800 | 300 ~500 |
NYSZ-1000 | 4 | 43 | twenty two | 0 ~1440 | 1200 | 500 ~1000 |
NYSZ-1500 | 7.5 | 38 | 30 | 0 ~1200 | 1400 | 1000 ~1500 |
Driven by the power unit, the stirring paddle rotates in a fixed direction. In the process of rotation, the material is driven to rotate axially and radially. The materials in the mixer have axial and circular motions at the same time, so there are several stirring forms such as shear stirring and diffusion stirring at the same time. It can effectively stir and mix materials quickly. The dispersing disc rotates at a high speed to make the material flow in an annular shape, generating a strong vortex, and descending to the bottom of the vortex in a spiral shape. Strong shearing, impact and friction are generated between the particles to achieve the function of rapid dispersion and dissolution. The circular motion of the mixing disc produces a good radial force, accelerates the circulation of the material, and improves the dispersion efficiency. The precise processing technology of the emulsifying head, the high degree of coordination between the rotor and the stator. The powerful motor rotates at high speed to form a vacuum between the rotor and the stator, and the material is sucked in from the upper and bottom of the rotor and the stator. The strong kinetic energy makes the rotor produce extremely high linear velocity, so that the material will fly out after strong impact, crushing, centrifugation, liquid layer friction, and strong shear between the rotation and the stator gap, under the action of various forces in different directions. , Produce strong turbulence. The material undergoes repeated cycles of depolymerization, dispersion, homogenization, refinement, and shearing to produce a stable emulsion after a certain amount of emulsifier and mature technology for a certain period of time. The hydraulic lifting three-axis mixer drives the hydraulic plunger up and down through the work of the hydraulic pump, driving the entire transmission mechanism and the working group to up and down.
